ESR Series Routers Operation Manual 83
Specify previously imported certificates and keys that will be used with OpenVPN server:
esr(config-openvpn)# certificate ca ca.crt
esr(config-openvpn)# certificate dh dh.pem
esr(config-openvpn)# certificate server-key server.key
esr(config-openvpn)# certificate server-crt server.crt
esr(config-openvpn)# certificate ta ta.key
Specify security zone that user sessions will be related to:
esr(config-openvpn)# security-zone VPN
Select aes128 encryption algorithm:
esr(config-openvpn)# encryption algorithm aes128
Enable OpenVPN server:
esr(config-openvpn)# enable
When a new configuration is applied, the router will listen to port 1194 (used by default).
To view OpenVPN server session status, use the following command:
esr# show remote-access status openvpn server AP
To view OpenVPN server session counters, use the following command:
esr# show remote-access counters openvpn server AP
To clear OpenVPN server session counters, use the following command:
esr# clear remote-access counters openvpn server AP
To end OpenVPN server session for user 'fedor', use one of the following commands:
esr# clear remote-access session openvpn username fedor
esr# clear remote-access session openvpn server AP username fedor
To view OpenVPN server configuration, use the following command:
esr# show remote-access configuration openvpn AP
In addition to OpenVPN server creation, you should open TCP port 1194 in the firewall.
7.24 Dual-Homing Configuration
1
Dual-Homing is a technology based on redundant links that creates a secure connection in order to
prevent failures of the key network resources.
1
In the current firmware version, this functionality is supported only by ESR-1000 router.
