To ensure the correct IP address assigning for the interface, enter the following command when the
configuration is applied:
esr# show ip interfaces
IP address Interface Type
------------------- --------------------------------- -------
192.168.16.144/24 gigabitethernet 1/0/2.150 static
Provider may use dynamically assigned addresses in their network. If the there is DHCP server in the
network, you can obtain the IP address via DHCP protocol.
 Configuration example for obtaining dynamic IP address from DHCP server on GigabitEthernet
1/0/10 interface:
esr# configure
esr(config)# interface gigabitethernet 1/0/10
esr(config-if)# ip address dhcp enable
esr(config-if)# exit
To ensure the correct IP address assigning for the interface, enter the following command when the
configuration is applied:
esr# show ip interfaces
IP address Interface Type
------------------- --------------------------------- -------
192.168.11.5/25 gigabitethernet 1/0/10 DHCP
5.2.2.5 Configuring remote connection to router
In the factory configuration, remote access to the router may be established via Telnet or SSH from
the 'trusted' zone. To enable remote access to the router from other zones, e.g. from the public network,
you should create the respective rules in the firewall.
When configuring access to the router, rules should be created for the following pair of zones:
 source-zone—zone that the remote access will originate from
 self—zone which includes router management interface
Use the following commands to create the allowing rule:
esr# configure
esr(config)# security zone-pair <source-zone> self
esr(config-zone-pair)# rule <number>
esr(config-zone-rule)# action permit
esr(config-zone-rule)# match protocol tcp
esr(config-zone-rule)# match source-address <network object-group>
esr(config-zone-rule)# match destination-address <network object-group>
esr(config-zone-rule)# match source-port any
esr(config-zone-rule)# match destination-port <service object-group>
esr(config-zone-rule)# enable
esr(config-zone-rule)# exit
esr(config-zone-pair)# exit
 Example of commands that allow users from 'untrusted' zone with IP addresses in range 132.16.0.5-
132.16.0.10 to connect to the router with IP address 40.13.1.22 via SSH:
