ELTEX NTU-RG-1421G-WZ User Manual

____________________________________________________________________________________
____________________________________________________________________________________
10 NTU Optical Network Terminals
(OMCI) specification
IEEE 802.1Q Tagged VLAN
IEEE 802.1p Priority Queues
IEEE 802.1D Spanning Tree Protocol
Connector type
SC/APC
Complies with ITU #T G.984.2
Transmission medium
Fibre optical cable SMF - 9/125, G.652
Splitting ratio
up to 1:128
Maximum range of coverage
20 km
Transmitter:
1310nm
Upstream connection speed
1244Mbps
Transmitter power
from +0.5 to +5 dBm
Optical spectrum width (RMS)
1 nm
Receiver
1490nm
Downstream connection speed
2488Mbps
Receiver sensitivity
from -8 to -28 dBm
Parameters of analogue user ports
Number of ports
1
Loop resistance
up to 2kΩ
Dialling
pulse/frequency (DTMF)
Caller ID display
yes
Wi-Fi Interface Specifications
Model
NTU-RG-1421G-Wac, NTU-RG-1421GC-Wac
NTU-RG-1431G-Wac
Standard
802.11a/b/g/n/ac
802.11a/b/g/n/ac
Frequency range
2400 ~ 2483.5MHz, 5150 ~ 5350MHz, 5650
~ 5850MHz
Simultaneous dual-band operation
2400 ~ 2483.5MHz, 5150 ~ 5350MHz, 5650 ~
5850MHz
Simultaneous dual-band operation
Modulation
CCK, BPSK, QPSK, 16 QAM, 64 QAM, 256
QAM
CCK, BPSK, QPSK, 16 QAM, 64 QAM, 256
QAM
Data rate, Mbps
– 802.11b/g/n: 1-13
– 802.11a/ac: 36-64, 132-165
– 802.11b: 1, 2, 5.5 and 11Mbps
– 802.11g: 6, 9, 12, 18, 24, 36, 48 and
54Mbps
– 802.11n: 300Mbps (20MHz channel),
450Mbps (40MHz channel)
– 802.11ac: 1300Mbps (80MHz)
– 802.11b/g/n: 1-13
– 802.11a/ac: 36-64, 132-165
– 802.11b: 1, 2, 5.5 and 11Mbps
– 802.11g: 6, 9, 12, 18, 24, 36, 48 and
54Mbps
– 802.11n: 300Mbps (20MHz channel),
450Mbps (40MHz channel)
– 802.11ac: 1300Mbps (80MHz)
Maximum transmitter
output power
– 802.11b (11Mbps): 17dBm
– 802.11g (54Mbps): 15dBm
– 802.11n (MCS7): 15dBm
– 802.11ас (5GHz): 19dBm
MAC protocol
CSMA/CA, ACK 32 MAC model
Security
64/128 bit WEP encryption
WPA, WPA2
802.1x
AES &TKIP
Supported operating
systems
Windows XP 32/64, Windows Vista 32/64, Windows 2000, Windows 7 32/64
Linux, VxWorks
MIMO
NTU-RG-1421G-Wac
2.4 GHz - 2х2, 5 GHz- 3х3
NTU-RG-1431G-Wac
2.4 GHz - 3х3, 5 GHz - 3х3
NTU-RG-1421GC-Wac
2.4 GHz - 2х2, 5 GHz - 3х3
Antenna gain
5dBi

ELTEX NTU-RG-1421G-WZ Specifications

General

Brand	ELTEX
Model	NTU-RG-1421G-WZ
Category	Touch terminals
Language	English
