ELTRA CS-580A Operating Manual

Analysis
20
2
CO2 outlet
3
Glass distributor
4
Connection to the furnace
5
Acid supply
6
50 ml glass flask
7
Heater with magnetic stirrer
8
Elevator with variable height
9
Acid
10
Furnace
11
Analyzer
12
Moisture trap
13
TIC/TC toggle
3.2.3 TIC-module installation
1. The TIC module is placed next to the analyzer.
2. Connect the mains power plug to a power socket.
3. Connect the TIC module and the analyzer with the provided tubes. The
connectors are located at the backside of the analyzer and of the TIC-
module.
4. The outlet of the furnace is connected via the H
2
O trap to the connection (2)
and finally to the inlet (1) of the TIC module.
5. Inside the TIC module, this tube is connected to the input of the glass
distributor (3) (connection on top tube 4).
6. The bottle of acid with dispenser (9) is placed to the right of the platform (8)
and it is connected to the connection (5) of the glass distributor.
7. The glass distributor (3) with the glass flask (6) is adjusted properly when the
whole surface of the bottom of the glass flask (6) touches the surface of the
heater (7).
8. The heater (7) is switched on and the temperature is set to 75°C.
9. The stirrer is set to 400.
