Emaldo Power Core User Manual
37
Copyright©EMALDO
Important
• Equipment damage caused by incorrect wiring is not covered by the warranty for the
equipment.
• The relevant operations of electrical connections must be completed by professional
electrical technicians.
• When implementing electrical connections, operators must wear personal protective
equipment.
Notes:
Please pay attention to the
wiring sequence of the devices.
The cable colors involved in all
electrical connection diagrams in
this chapter are for reference
only, and the selection of cables
shall conform to local cable
standards (yellow and green dual
color wires can only be used for
protective grounding).
Emaldo Power Core is a
transformer free energy storage
system, and all other assemblies
in the photovoltaic system must
be compatible with this type of
energy storage system
architecture.
