10. Connect the communication cable to terminals A1 (21) and B1 (22) of the instrument.
11. Connect the other end of the communication cable to the COM port of Emaldo Power Core
12. Note: The instrument is connected to the current transformer (CT). The shunt current
transformer (CT) is connected. It is used for existing wiring to detect the maximum
continuous rated current (AC) of 150A coming from the power grid.
4.6 Inspection after installation
No
Inspection criteria
1
The energy storage system is installed correctly and securely.
2
The cable layout is reasonable and meets user requirements.
3
The cable tie shall be uniform and cut without leaving sharp corners.
4
The grounding wire is connected correctly, firmly and reliably.
5
The switch and all switches connected to the energy storage are in the "OFF" state.
6
AC cable, Grid cable, and electricity meter communication cable are connected correctly, firmly and
reliably.
7
Install waterproof covers on unused terminals and interfaces.
8
The installation space is reasonable, the environment is clean and tidy, and there are no construction
remnants.
