Emaldo Power Core User Manual
Important
• Secure the distribution box with M8 expansion bolts provided. If its length or quantity
cannot meet the installation requirements, please provide M8 stainless steel expansion
bolts for yourselves.
• In order to prevent dust from entering human respiratory tract or falling into eyes during
drilling, operators shall wear protective glasses and dust masks.
• Dust inside and outside all holes shall be removed by the dust collector, and then the hole
spacing shall be measured. For holes with large errors, relocation and drilling shall be
carried out.
• After bolts, spring washers and flat washers are unscrewed, the upper end surface of the
expansion pipe must be level with the cement wall surface or the floor without protruding
out of the cement wall surface and the floor; otherwise, the engineering installation parts
cannot be placed evenly on the wall surface.
4 Electrical Connection
4.1 Wiring for energy storage system
The system wiring mainly includes two parts:
• Wiring for the Emaldo Power Core and Additional Cabinet. There will be three cables
connected to the Additional Cabinet in the upper leading-out cabin on the right side of the
Emaldo Power Core, namely Grid cable, AC cable and COM electricity meter
communication cable.
• The Additional Cabinet is already connected to the user's primary distribution box. The
cables are used for electricity selling RCD of Additional Cabinet, ATS automatic changeover
switch output, and bidirectional electricity meter sampling.
