POWERJET MANUAL
8f749dd9-8865-44fd-baed-1b68166d2198file.doc
POWERJET OWNERS INSTALL & OPERATE MANUAL
16
16
Wiring Diagram for :
EMC
®
POWERJET
®
For Model: 2846E and 4046E
dwg: PJ-2846E-4046E-5HP-440V-3PH-20A
BC-03-23-2005
AUTOMATIC PARTS WASHER
Electric Heated (440V)
with Optional 5HP pump Motor (3)
440Volt / 3 (three phase) / 20Amps
Drawing Not to Scale
DOOR
SWITCH
THERMO
-STAT
30 min.
PUMP
TIMER
BULB
BULB
7 - DAY
TIMER
PUMP CONTACTOR
Over Load Relay
HEATER CONTACTOR
TO
TURNTABLE
MOTOR
AC POWER IN
440V, 3, 20A
Ground to chassis
Control Box
Front View
Control Box
Rear View
Control Box Side View
(cover removed)
Electric models:
2846E, 4046E,
5HP,
440V-3ph-20A
Thermostat Probe in sleeve
Heater Box Cover
(cut-away view)
Drawing Not to Scale
Float
Switch
440V, 4500W,
Heater Terminals
1 LINK
440Volt
100VA
TRANSFORMER
Note:
Unit will operate at
400V to 480V,
3 phase power
PUMP ROTATION
CLOCKWISE FROM TOP
Drawing Not to Scale
Heavy Duty, 280GPM,
SEALLESS PUMP
5HP,
3 Phase,
MOTOR
IMPORTANT !
CHECK THAT PUMP
MOTOR ROTATION IS
CLOCKWISE AS
VIEWED FROM TOP !
PUMP
WELL
30
20
10
Turn
Past
0FF
MINUTES
OFF
220
120
160
200
180
140
100
Copper Capillary Tubing
