EMC POWERJET User Manual

POWERJET MANUAL
8f749dd9-8865-44fd-baed-1b68166d2198file.doc POWERJET OWNERS INSTALL & OPERATE MANUAL
20
20
PARTS & ACCESSORIES for models 2846 – 4046 – 5846
POWERJET® SYSTEM - Replaceable Parts and Accessories available at EMC
EMC Item No.
Name of Part and Details
SOLUTION SAVER ™ SYSTEM
PJ112
2’’ BALL VALVE for Drain or Skimmer
PJ116
FILTER BAGS 100 micron (fine) ...Not available at EMC anymore, ...available at Grainger p/n 4BB84
PJ117
FILTER BAGS 400 micron (medium) Not available at EMC anymore, ...available at Grainger p/n 4BB94
PJ118
FILTER BAGS standard 800 micron (coarse) ...also available at Grainger p/n 4BB98
ROTOR DRIVE SYSTEM
PJ119-s
TOP COVER for TurnTable Drive Assembly, covers GearMotor and Bearing with 5” Pulley and 20”Belt (4L200 belt)
PJ119-L
Large TOP COVER . . for 10” Pulley with 36” Belt (3L360),on model 4046 or Larger (since 3-‘015, ..begin s/n9296215)
PJ120
DRIVE MOTOR, with 2” Pulley attached at EMC, ..just the Motor Only (no pulley) is available at Grainger p/n 3M095 or 1MBF4
PJ121
MOTOR MOUNT BRACKET . . . for smaller 5” Pulley with 20” Belt
PJ121- LB
Motor Draw Bolt L-BRACKET (hardware kit) . . . for larger 10” Pulley with 36” Belt
PJ122-20
DRIVE BELT . . . 20” belt for ALL units with 5” Pulley, belt no. 4L200
PJ122-36
DRIVE BELT . . . 36” belt for units with 10” Pulley, belt no. 3L360
ROTOR BEARING ASSEMBLY
PJ123
JAM NUT . . . (shorter nut)
PJ124-5
ROTOR PULLEY (Driven Pulley) 5” Pulley (since 9-’05), fits ALL units with a 4L200 Belt (20”) Grngr p/n 3X917
PJ124-10
ROTOR PULLEY (Driven Pulley) 10” Pulley ..on model 4046 and larger (since March 2015) (begin s/n9296215)
PJ126
SPINDLE NUT . . . (taller nut)
PJ127
ROLLER BEARING CONE & CUP ASSEMBLY
PJ128
STAND-OFF SHIMS, under Bearing – 2 pieces
PJ129
SPINDLE SEAL . . . ¾” ID, grooved “O”-ring rubber seal
PJ130-5.5
SPINDLE BOLT . . . ¾” x 5½” Grade 8
PJ130-5.5-SS
SPINDLE BOLT . . . ¾” x 5½” Grade 8 - STAINLESS Steel
EASY RACK ® FIXTURING SYSTEM
TTS28
TurnTable SHELF . . . for model 2846, and other heights
TTS40
TurnTable SHELF . . . for model 4046, and other heights
TTS58
TurnTable SHELF . . . for model 5846, and other heights
524PB
Parts BASKET, …standard size, …fits ALL models, . . . . 5½”deep x 24”diameter
531PB
Parts BASKET, …option size, …fits model 4046 & 5846, . . . 5½”deep x 31”diameter ( for old model 100 )
537PB
Parts BASKET, …option size, …fits model 4046 & 5846, . . . 5½”deep x 37”diameter
553PB
Parts BASKET, …option size, …fits model 5846, . . . . 5½”deep x 53”diameter
24PT
shallow Parts TRAY . . . fits ALL models, . . . . ⅜”deep x 24”diameter
31PT
shallow Parts TRAY . . . fits model 4046 & 5846, . . ⅜”deep x 31”diameter
37PT
shallow Parts TRAY . . . fits model 4046 & 5846, . . ⅜”deep x 37”diameter
53PT
shallow Parts TRAY . . . fits model 5846, . . . . ⅜”deep x 53”diameter
1010SPB
Small Parts BASKET, . . 8” deep + 5” handle x 10” diameter
1216SPB
Small Parts BASKET, . . 12” deep x 16” diameter
PJ131- x x x x
TurnTable ROTOR -2846, -4046, -5846, etc.
PJ132
ROTOR CLAMP
PJ133
Threaded PIN
PJ134
Threaded “L”
PJ135
Threaded HOOK
PJ136
All Threaded CROSS BAR
PJ137
PARTS CLAMP
PJ138
SWING ARM
PJ139
4-way Threaded “CROSS” ( FFFF )
PJ140
3-way Threaded “CROSS” ( FFF )
PJ141
3-way Threaded “TEE” ( FFM )
THERMAL GUARD ™ SYSTEM
PJ170- x x x x
VENT DAMPER RUBBER FLAPPER -2846, -4046, -5846, etc.
PJ171- x x x x
DOOR SEAL -2846, -4046, -5846, -x x x x (..and other lengths)
PJ172
DOOR HANDLE
PJ173
DOOR LATCH PIN

EMC POWERJET Specifications

General

Brand	EMC
Model	POWERJET
Category	Industrial Equipment
Language	English
