EMC POWERJET User Manual

POWERJET MANUAL
8f749dd9-8865-44fd-baed-1b68166d2198file.doc POWERJET OWNERS INSTALL & OPERATE MANUAL
21
21
PARTS & ACCESSORIES for models 2846 – 4046 – 5846
THESE COMPONENTS available at EMC ® and ALSO available at GRAINGER
EMC Item No.
Name of Part
Details
Ship Weight
Grainger p/n
CABINET
TANK ITEM
PJ108
FLOAT SWITCH
for Low Water Level shutdown
1
2A551
CONTROL BOX ITEMS
PJ202
TRANSFORMER 100 VA
for ELECTRIC ONLY
5
4R822
PJ204
CONTACTOR
1 for Heaters or 1 for pump Motor
3
5B109
PJ204-A44
OVER LOAD RELAY
for 440Volt, 3-Phase units
with std 1½HP pump Motor
1
3EA44
PJ204-A46
OVER LOAD RELAY
for 440Volt, 3-Phase units
with 5HP Sealless pump Motor
1
3EA46
PJ204-A11
OVER LOAD RELAY
for 220Volt, 3-Phase units
with 5HP Sealless pump Motor
1
3EA11
PJ205
DOOR Micro-SWITCH
“Door Safety Switch”
1
6X288
PJ207
30 minute TIMER
Pump Timer
1
2E175
OTHER Replaceable COMPONENTS available at EMC ® OR from Sales Distributor
EMC Item No.
Name of Part
Details
Ship Weight
CONTROL BOX ITEMS
PJ-SS7C
7-Day TIMER - DIGITAL- * DISCONTINUED *
Intermatic SS7C Digital Timer - * DISCONTINUED *
N/A
PJ201-RP
7-Day TIMER - ANALOG (standard 2008)
with RED set pins, *replacement for Digital above*
1
GPJ203
TRANSFORMER 500 VA
for GAS units ONLY
PJ206
Indicator BULB
2 bulbs per unit
1
PJ208
THERMOSTAT
with copper capillary tubing and heat probe sensor
1
PJ208-K
Thermostat KNOB
degrees-numbered dial knob
1
STANDARD PUMP & MOTOR ITEMS
PSK300
PUMP SEAL KIT includes:
2 Seals with 2 Lube packs, and 1 O-Ring
PJ301-1ph
Std. Pump MOTOR, 220V, 1-phase
1½HP, 56J-ODP
25
PJ301-3ph
Std. Pump MOTOR, 440V, 3-phase
1½HP, 56J-ODP
25
PJ302
Std. PUMP ASSEMBLY
cast iron Volute & motor-Adapter, Impeller, Seal
23
PJ303
Std. Pump SEAL
2 piece seal, 1R303 at Grainger
1
PJ304
Std. Pump O-RING
4½” diameter rubber O-ring
1
PJ305
Std. Pump IMPELLER
4⅜” diameter
3
PJ306
Std. Pump ADAPTOR (upper end)
“adapts” motor to pump – cast iron
8
PJ307
Std. Pump VOLUTE (lower end)
Pump inlet and outlet – cast iron
12
ELECTRIC HEATING ELEMENTS
220LWD4500
Low Watt Density HEATER Element
220V, 4500W
3
440LWD4500
Low Watt Density HEATER Element
440V, 4500W
3
Use Teflon Tape
on brass threads
SEALLESS PUMP & MOTOR ITEMS
SLP321-3ph
SealLess Pump MOTOR, 3-phase, 5HP
220V or 440V, 3-phase, MOTOR Replacement
85
SLP321-1ph
SealLess Pump MOTOR, 1-phase, 5HP
220V, 1-phase, MOTOR UpGrade -220V only
85
SLP322
SealLess Pump GREASE SEAL
Nat’l Seal No.471192, at Auto Parts or Bearing & Seal stores,
..Not at EMC
SLP323
SealLess Pump & Motor ADAPTOR
12” cast iron column, upper end
21
SLP324
SealLess Pump WELL
10’’diam.x 10’’deep, fittings custom fit & welded at EMC
16
SLP325
SealLess Pump Well Gasket Sealer
Use 3M brand 5200 Poly-Urethane Sealer
SLP326
SealLessPump THROTTLE SLEEVE
(motor shaft bushing)
1
SLP327
SealLess Pump IMPELLER
5½” diameter
3
SLP328
SealLess PUMP CASE (VOLUTE)
cast iron case, lower end
18
SLP329
SealLessPump PLUMBING HOSE
1½” to 1½”, with hose clamps
1
