EMC VNX Series Hardware Information Guide

156 EMC VNX8000 Hardware Information Guide
Eight- and sixteen-bus DAE cabling
Slot 4 (sixteen-bus) configuration
The following figure shows the location of the 6-Gb/s SAS I/O module slot (slot 4), the I/O
module port locations (0, 1, 2, and 3), and the cable labels for both the I/O module side
and the corresponding LCC side in the DAE it connects to (Figure 125 on page 156). For
more information, refer to Table 56 on page 154.
Figure 125 Example of a 16-bus factory version of a VNX8000 with the 6-Gb/s SAS I/O module in
slot 4
B
0123
A
0123
0123
0123
0123
0123
0123
0123
SP A SAS 4 Port 1
SP A SAS 4 Port 2
LCC A
SP A SAS 4 Port 3
LCC A
LCC A
LCC A
A BE2
A BE3
A BE4
LCC B
LCC B
LCC B
SP B SAS 4 Port 1
SP B SAS 4 Port 0
SP B SAS 4 Port 3
SP B SAS 4 Port 2
LCC B
A BE1
SP A SAS 4 Port 0
A BE2
A BE3
A BE4
A BE1
B BE2
B BE3
B BE4
B BE1
B BE2
B BE3
B BE4
B BE1
VNX-000827

EMC VNX Series Specifications

General

Management Interface	Unisphere
Drive Support	SAS, NL-SAS, Flash (SSD)
RAID Levels	RAID 0, 1, 3, 5, 6
Protocols Supported	Fibre Channel, iSCSI, NFS, CIFS
Data Services	Deduplication, Compression, Snapshots, Replication
Processor	Intel Xeon
Operating System	VNX Operating Environment (block), VNX File Operating Environment (file)
