Eight- and sixteen-bus DAE cabling
EMC VNX8000 Hardware Information Guide 155
As described in Table 56, the resulting numbering scheme for a sixteen-bus VNX8000
shipped from the factory is shown in Figure 125 on page 156 through Figure 128 on
page 159. These figures show the 6-Gb/s SAS I/O module slot location, port location in
the I/O module, and the cable with cable labels from the I/O module side to the LCC side
on the respective DAE.
◆ “Slot 4 (sixteen-bus) configuration” on page 156
◆ “Slot 5 (sixteen-bus) configuration” on page 157
◆ “Slot 6 (sixteen-bus) configuration” on page 158
◆ “Slot 10 (sixteen-bus) configuration” on page 159
The next two illustrations show examples of how the 2U, 25 DAEs are deployed in two 40U
racks of a Block interleaved and a Block stacked sixteen-bus system.
◆ “Sixteen-bus factory-shipped Block interleaved configuration” on page 160
◆ “Sixteen-bus factory-shipped Block stacked configuration” on page 161
10 1 13 SP A SAS 10 Port 1
SP B SAS 10 Port 1
Dark gray/green
10 2 14 SP A SAS 10 Port 2
SP B SAS 10 Port 2
Light gray
10 3 15 SP A SAS 10 Port 3
SP B SAS 10 Port 3
Peach
Table 56 A (sixteen-bus) VNX8000 scenario
I/O module slot
number Port
Back-end
loop #
SP A an B cable labels
(white w/black text)
Back-end loop cable
label colors
