EMC VNX Series Hardware Information Guide

Eight- and sixteen-bus DAE cabling
EMC VNX8000 Hardware Information Guide 157
Slot 5 (sixteen-bus) configuration
The following figure shows the location of the 6-Gb/s SAS I/O module slot (slot 5), the I/O
module port locations (0, 1, 2, and 3), and the cable labels for both the I/O module side
and the corresponding LCC side in the DAE it connects to (Figure 126). For more
information, refer to Table 56 on page 154.
Figure 126 Example continuation of a sixteen-bus factory version of a VNX8000 with the 6-Gb/s
SAS I/O module in slot 5
0123
0123
0123
0123
0123
0123
0123
0123
B
A
SP B SAS 5 Port 0
SP B SAS 5 Port 3
B BE7
LCC B
B BE6
LCC B
B BE5
LCC B
B BE0
LCC B
B BE7
SP B SAS 5 Port 2
B BE6
SP B SAS 5 Port 1
B BE5
B BE0
LCC A
A BE5
LCC A
A BE7
LCC A
A BE0
A BE0
A BE5
A BE7
A BE6
LCC A
A BE6
SP A SAS 5 Port 3
SP A SAS 5 Port 1
SP A SAS 5 Port 0
SP A SAS 5 Port 2
VNX-000828

EMC VNX Series Specifications

General

Management Interface	Unisphere
Drive Support	SAS, NL-SAS, Flash (SSD)
RAID Levels	RAID 0, 1, 3, 5, 6
Protocols Supported	Fibre Channel, iSCSI, NFS, CIFS
Data Services	Deduplication, Compression, Snapshots, Replication
Processor	Intel Xeon
Operating System	VNX Operating Environment (block), VNX File Operating Environment (file)
