EMC VNX Series Hardware Information Guide

164 EMC VNX8000 Hardware Information Guide
Eight- and sixteen-bus DAE cabling
Slot 10 (eight-bus) configuration
The following figure shows the location of the 6-Gb/s SAS I/O module slot (slot 10), the
I/O module port location (0, 1, 2, and 3), and the cable labels for both the I/O module
side and the corresponding LCC side in the DAE it connects to (Figure 132). For more
information, refer to Table 57 on page 162.
Figure 132 Example continuation of an eight-bus configuration of a VNX8000 platform with the
SAS I/O module in slot 10
B
0123
0123
A
0123
0123
SP A SAS 10 Port 0
SP A SAS 10 Port 1
SP A SAS 10 Port 2
LCC A
A BE4
SP A SAS 10 Port 3
LCC A
A BE7
LCC A
A BE6
LCC A
A BE5
A BE4
A BE5
A BE6
A BE7
LCC B
B BE7
LCC B
B BE4
LCC B
B BE5
B BE7
B BE4
B BE5
B BE6
SP B SAS 10 Port 1
SP B SAS 10 Port 0
SP B SAS 10 Port 3
SP B SAS 10 Port 2
LCC B
B BE6
VNX-000826

EMC VNX Series Specifications

General

Management Interface	Unisphere
Drive Support	SAS, NL-SAS, Flash (SSD)
RAID Levels	RAID 0, 1, 3, 5, 6
Protocols Supported	Fibre Channel, iSCSI, NFS, CIFS
Data Services	Deduplication, Compression, Snapshots, Replication
Processor	Intel Xeon
Operating System	VNX Operating Environment (block), VNX File Operating Environment (file)
