DPSI RV Family Operating Instructions Version 2.0
Page 8 of 48
Hint:
On delivery, the DPSI RV system’s low voltage recognition is programmed for 2-
cell LiPo batteries. For using other battery types, the corresponding type must be
programmed first (see chapter 5.9)!
The output voltage is set to 5.6 volts on delivery (DPSI 2001 RV 5.9 volts – other
values on customer request possible).
Different versions:
In order to satisfy all applications, different DPSI RV versions are
available:
The DPSI RV Mini 5 addresses pilots of the 2 to 2.5 meter aerobatic
class, who do not need too many servos for their model and where
only up to two servos maximum work on one flap. Therefore, only
heavily loaded rudders are supplied by the DPSI (aileron, elevator, yaw
rudder). Servos for further functions can be connected directly to the
receiver (e.g. engine throttle, retractable gear, etc.)
The DPSI RV Mini 6 is primarily intended for jet- and glider-pilots (but
suits motorized models too), where more channels are needed but
where only one
servo works on a flap. Here too, additional servos can
be connected directly to the receiver.
