Charge the battery pack
The analyzer is fully operational during charging. As a best practice, charge
the battery pack frequently. Emerson recommends you charge the battery
pack the night before you intend to use it.
WARNING!
• Use only Emerson-supplied power supplies and chargers approved for use
with the CSI 2140 and Emerson battery packs. Using any power supplies
and chargers other than approved Emerson power supplies and battery
packs could not only void the warranty, but will also most likely damage
the analyzer or the battery pack.
• When charging the CSI 2140 with the battery pack or the battery pack by
itself, ensure the ambient temperature where charging is occurring is 50°
F to 95° F (10° C to 35° C).
• Charge the battery pack only in a non-hazardous area.
Procedure
1.
Remove the rubber plug on the top of the analyzer.
2. Insert the power supply connector into the analyzer. The analyzer can be
powered on or off.
3. Plug the AC connector on the power supply into a standard AC outlet,
ranging from 100 VAC to 250 VAC, 50-60 Hz. A full recharge may take
four hours.
The back of the analyzer may feel warm during charging. The power
supply can remain connected to the analyzer after charging completes.
You cannot overcharge the battery pack.
Attach the shoulder strap
1. Press and hold the button on the strap connector, and insert it into the
connectors on the sides of the analyzer or the CSI 2140 Four-Channel
Input Adapter, if attached.
2. To release the strap, press and hold the button on the connector and
then pull.
Use the stand
1. To put the stand in the upright position, grab the stand and pull up until
the stand locks.
2. To release the stand, place the analyzer face down, grab the base of the
stand, and gently pull.
Quick Start Guide March 2016
8 MHM-97430 Rev 4
