WARNING
CRUSHING HAZARD
Do not remove flange stabilizers.
Attempting to do so may allow the meter to roll, resulting in serious injury or
equipment damage.
A. Flange stabilizers
WARNING
FLUID CONTENTS MAY BE UNDER PRESSURE
When the meter is under pressure, DO NOT attempt to remove or adjust the transducer
holder.
Attempting to do so may release pressurized gas or fluid, resulting in serious injury or
equipment damage.
WARNING
CONTENTS MAY BE HAZARDOUS
The meter must be fully depressurized and drained before attempting to remove the
transducer holder of T-Slot transducer assembly, or the T-200 transducer assembly. If
gas or fluid begins to leak from the transducer holder of T-Slot transducer assembly, or
T-200 transducer stalk assembly, stop immediately and reinstall the transducer holder
or T-200 transducer stalk assembly.
Failure to comply may cause serious injury or equipment damage.
A. Transducer holder
Meter repairs Maintenance and Troubleshooting manual
June 2019 P/N 3-9000-769
52 Gas Ultrasonic Flow Meters
