Owner and operator manual Section 5: Supplemental information
3-9008-001 Rev M January 2015
Recommended spare parts for one-year operation 97
Section 5: Supplemental information
5.1 Recommended spare parts for one-year operation
Materials listed above are for standard “A” trim assemblies. For other trim options, consult with
a Daniel representative for materials of components which are different.
Important
See ordering information in Section 1: Introduction.
Table 5-1 Recommended spare parts
Item No. Weight Description Material Quantity
5 150-2500 Shaft CS (ZP) 1
8E 150-600 Orifice Plate Sealing Unit Nitrile 5
8TS 900-2500 Orifice Plate Sealing Unit Teflon 3
9A 150-900 Sealing Bar Gasket Composition 5
9CF 1500-2500 Sealing Bar Gasket Synthetic Composition 3
11 150-2500 Clamping Bar Screws Alloy Steel, (ZP) 2
18A 150-900 Slide Valve Seat/Top Gasket Composition 1
18A 1500 Slide Valve Seat/Top Gasket Composition 1
14CF 1500 Body/Top Gasket (o-ring) Special Compound 1
14CF-A 2500 Body/Top Gasket Parker Seal 1
22A 150-1500 Stuffing Box/Bearing Plug Gasket Stainless Steel 2
22A 2500 Stuffing Box/Bearing Plug Gasket Stainless Steel 2
22B 2500 Stuffing Box/Bearing Plug O-Ring Nitrile 2
25A 150-1500 Packing Rings Teflon 1-SET
25A-HP 2500 Packing Rings Teflon 1-SET
25B 150-1500 Centering Rings Teflon 1-SET
25B-HP 2500 Centering Rings Teflon 1-SET
26C 2500 External Gland Outer O-Ring Nitrile 1
26D 2500 External Gland Inner O-Ring Nitrile 1
26D 2500 Internal Gland O-Ring Nitrile 1
150-2500 Slide Valve Lubricant 3 BOXES
