Appendix 1 Parameters 97
EV2000 Series Universal Variable Speed Drive User Manual
Group F5: Close-loop control parameters
Para. Name LCD Display Setting range Unit
Factory
setting
Modif.
F5.18
Close-loop preset
frequency
CLOSELOOP PRESET
FREQ
0.00~650.0Hz 0.01Hz 0.00Hz
○
F5.19
Holding time of
close-loop preset
frequency
PRESET HOLD TIME 0.0~3600s 0.1s 0.0s
×
F5.20
Preset close-loop
reference 1
CLOSELOOP REF1 0.00V~10.00V 0.01V 0.00V
○
F5.21
Preset close-loop
reference 2
CLOSELOOP REF2 0.00V~10.00V 0.01V 0.00V
○
F5.22
Preset close-loop
reference 3
CLOSELOOP REF3 0.00V~10.00V 0.01V 0.00V
○
F5.23
Preset close-loop
reference 4
CLOSELOOP REF4 0.00V~10.00V 0.01V 0.00V
○
F5.24
Preset close-loop
reference 5
CLOSELOOP REF5 0.00V~10.00V 0.01V 0.00V
○
F5.25
Preset close-loop
reference 6
CLOSELOOP REF6 0.00V~10.00V 0.01V 0.00V
○
F5.26
Preset close-loop
reference 7
CLOSELOOP REF7 0.00V~10.00V 0.01V 0.00V
○
Group F6: Textile Operating Function Parameters
Para. Name LCD Display Setting Range Unit
Factory
Setting
Modif.
F6.00
Textile function
selection
TEXTILE FUNC
SELE
0:Disabled 1:Enabled 1 0
×
F6.01
Traverse operation
control mode
SWING CTR
MODE
Unit’s place of LED: start mode
0:Auto mode (according to F6.03)
1:Manual mode
Ten’s place of LED: traverse operating amplitude
control
0:Variable amplitude
1:Fixed amplitude
Hundred’s place of LED: stopping mode of traverse
operation
0:Start at the frequency and direction memorized
before stopping
1:Re-start
Thousand’s place of LED: save parameters upon
power outage
0:Saving traverse operating status at power outage
1:Not saving traverse operating status at power outage
1 0000
×
F6.02
Pre-traverse
frequency
SWING BASE
FREQ
0.00Hz~650.0Hz 0.01Hz 0.00Hz
○
F6.03
Waiting time before
traverse
SWING WAIT
TIME
0.0~3600.0s 0.1s 0.0s
○
F6.04
Traverse operating
amplitude
SWING
AMPLITUDE
0.0~50.0% 0.1% 0.0%
○
F6.05 Jitter frequency
JUMP FREQ
0.0~50.0% (with reference to F6.04) 0.1% 0.0%
○
F6.06
Traverse operating
cycle
SWING CYCLE 0.1~999.9s 0.1s 10.0s
○
F6.07
Rising time of
triangle wave
RISE TIME
0.0~100.0% (with reference to traverse operating
cycle)
0.1% 50.0%
○
 Note:
The central frequency is the default present frequency setting (Settings of traverse operation are not active in Jog and close-loop
operation mode)
