118 Appendix 3 Communication Protocol
EV2000 Series Universal Variable Speed Drive User Manual
Name
Command
of master
Auxiliary
index
Command
index
Setting
range
Example Accuracy Notes
Operation control and adjustment function
Start-up of
slave
02 00 00 None ~010200000183\r None
Set present
reference
frequency of
slave
02 00 01
0Hz~upper
frequency
~0102000103E80264\r 0.01 Hz Frequency setting =10.00Hz
Frequency
setting at the
start-up of the
slave
02 00 02
0Hz~upper
frequency
limit
~0102000203E80265\r 0.01 Hz
Frequency setting at the
start-up of the slave
=10.00Hz
Forward
start-up of the
slave
02 00 03 None ~010200030186\r None
Forward
start-up of the
slave
02 00 04 None ~010200040187\r None
Frequency
setting at the
forward start-up
of the slave
02 00 05
0Hz~upper
frequency
limit
~0102000503E80268\r 0.01 Hz
Frequency setting at the
forward start-up of the slave
=10.00Hz
Frequency
setting at the
reverse start-up
of the slave
02 00 06
0Hz~ upper
frequency
limit
~0102000603E80269\r 0.01 Hz
Frequency setting at the
reverse start-up of the slave
=10.00Hz
Stop of slave
02 00 07 None ~01020007018A\r None
Jog operation of
slave
02 00 08 None ~01020008018B\r None
Forward jog
operation of
slave
02 00 09 None ~01020009018C\r None
Reverse jog
operation of
slave
02 00 0A None ~0102000A0194\r None
Stop the jog
operation of the
slave
02 00 0B None ~0102000B0195\r None
Reset the slave
upon failure
02 00 0C None ~0102000C0196\r None
Coast-to-stop of
slave
02 00 0D None ~0102000D0197\r None
Emergent stop
of slave
02 00 0E None ~0102000E0198\r None
Set the rate of
analog output
AO1
02 00 13 0~FFFF ~0102001333330253\r
0~65535
mapping
0~100%
Set AO1 output to 20%
Set the rate of
analog output
AO2
02 00 14 0~FFFF ~0102001433330254\r
0~65535
mapping
0~100%
Set AO2 output to 20%
Set the rate of
digital output
DO
02 00 15 0~FFFF ~0102001533330255\r
0~65535
mapping
0~100%
Set DO to 20%*F7.32 Hz
Ratio of
frequency
(preserved)
02 00 16 0~7D0 ~0102001603E8026A\r 0.1%
Set the frequency ratio to
100%
Set the terminal
status of
fictitious control
02 00 17 0~FFFF ~01020017FFFF02A3\r 1
Bit0~12: The fictitious
terminals X1~X8, FWD,
REV, Y1, Y2 and TC
