Table 4-85. Block Parameter Index (Continued)
Label Page Numbers
Index
Number
BlockParameter Name
Failed Suppress FAILED_MASK Transducer 65 4-35, 4-52, C-3
Fault State FAULT_STATE Resource 28 4-5, 4-15, NO TAG
Fault State Time FSTATE_TIME
AO 23 4-72, 4-77
DO 19 4-152, 4-155
Fault State Value FSTATE_VAL AO 24 4-72, 4-77
Fault State Value Discrete FSTATE_VAL_D DO 20 4-152, 4-155
Features Available FEATURES Resource 17 4-5, 4-13, 6-6
Feature Selected FEATURE_SEL Resource 18 4-5, 4-13
Feedback Connection FEEDBACK_CONN Transducer 42.4 4-38, 4-46
Feed Forward Gain FF_GAIN PID 42 4-86, 4-92
Feed Forward Scale FF_SCALE PID 41 4-86, 4-92
Feed Forward Value FF_VAL PID 40 4-86, 4-92
Field Serial Number FIELD_SN Resource 51 4-6, 4-17, 6-5
Field Value FIELD_VAL AI 19 4-129, 4-130, 4-135
Field Value Discrete FIELD_VAL_D DI 17 4-163, 4-164, 4-167
Flow Direction FLOWDIRECTION Transducer 84.5 4-37, 4-61
Flow Tends To FLOW_TENDS_TO Transducer 84.7 4-37, 4-61
Free Space FREE_SPACE Resource 24 4-14
Free Time FREE_TIME Resource 25 4-14
Function Block Options FB_OPTIONS Resource 44 4-5, 4-17, 6-6
Gain GAIN PID 23 4-83, 4-91
Grant Deny GRANT_DENY
AI 12 4-135
AO 13 4-76
DI 12 4-167
DO 13 4-155
ISEL 9 4-109
OS 12 4-124
PID 12 4-90
Resource 14 4-13
Transducer 40 4-45
Hard Types HARD_TYPES Resource 15 4-13
Hardware Revision HARDWARE_REV Resource 48 4-7, 4-17
Health Index HEALTH_INDEX Transducer 79 4-60
High Alarm HI_ALM
AI 34 4-136
ISEL 46 4-113
PID 61 4-94
High High Alarm HI_HI_ALM
AI 33 4-136
ISEL 45 4-112
PID 60 4-94
High High Limit HI_HI_LIM
AI 26 4-129, 4-136
ISEL 38 4-108, 4-112
PID 49 4-87, 4-93
High High Priority HI_HI_PRI
AI 25 4-129, 4-136
ISEL 37 4-108, 4-112
PID 48 4-87, 4-93
High Limit HI_LIM
AI 28 4-129, 4-136
ISEL 40 4-108, 4-112
PID 51 4-87, 4-93
High Priority HI_PRI
AI 27 4-129, 4-136
ISEL 39 4-108, 4-112
PID 50 4-87, 4-93
