Emerson Fisher FIELDVUE DVC6000f User Manual

All Blocks
December 2009
4-175
Table 4-85. Block Parameter Index (Continued)
Label Page Numbers
Index
Number
BlockParameter Name
Control Options CONTROL_OPTS PID 12 4-86, 4-90
Custom Points CUSTOM_POINTS Transducer 51 4-50
Cycle Counter CYCLE_COUNT Transducer 73 4-33, 4-53, 6-11
Cycle Counter Alert Point CYCLE_COUNT_ALRT_PT Transducer 77.6 4-34, 4-59
Cycle Counter Deadband CYCLE_COUNT_DB Transducer 77.7 4-34, 4-59
Cycle Selection CYCLE_SEL Resource 20 4-14
Cycle Type CYCLE_TYPE Resource 19 4-14
DD Resource DD_RESOURCE Resource 9 4-12
DD Revision DD_REV Resource 13 4-13
Detailed Status DETAILED_STATUS Resource 52 4-17
Deviation High Alarm DV_HI_ALM PID 64 4-95
Deviation High Limit DV_HI_LIM PID 57 4-87, 4-94
Deviation High Priority DV_HI_PRI PID 56 4-87, 4-94
Deviation Low Alarm DV_LO_ALM PID 65 4-95
Deviation Low Limit DV_LO_LIM PID 59 4-87, 4-94
Deviation Low Priority DV_LO_PRI PID 58 4-87, 4-94
Device ID DEVICE_ID Resource 54 4-6, 4-17, 6-5
Device Record DEVICE_RECORD Transducer 86 4-62
Device Revision DEV_REV Resource 12 4-7, 4-13, 6-5
Device State RS_STATE Resource 7 4-12, 6-3
Device String Array DEV_STRING Resource 43 4-17
Device Type DEV_TYPE Resource 11 4-6, 4-13, 6-5
Diagnostic Options DIAG_OPTIONS Resource 45 4-5, 4-17, 6-6
Disable Analog Input 1 DISABLE_1 ISEL 15 4-107, 4-110
Disable Analog Input 2 DISABLE_2 ISEL 16 4-107, 4-110
Disable Analog Input 3 DISABLE_3 ISEL 17 4-107, 4-110
Disable Analog Input 4 DISABLE_4 ISEL 18 4-107, 4-110
Disable Analog Input 5 DISABLE_5 ISEL 29 4-107, 4-111
Disable Analog Input 6 DISABLE_6 ISEL 30 4-107, 4-111
Disable Analog Input 7 DISABLE_7 ISEL 31 4-107, 4-111
Disable Analog Input 8 DISABLE_8 ISEL 32 4-107, 4-112
Discrete Alarm DISC_ALM DI 24 4-168
Discrete Limit DISC_LIM DI 23 4-163, 4-168
Discrete Priority DISC_PRI DI 22 4-168
Drive Current DRIVE_CURRENT Transducer 54 4-27, 4-50
Drive Current Alert Point DRIVE_CURRENT_ALRT_PT Transducer 76.4 4-27, 4-58
Drive Current Alert Time DRIVE_CURRENT_TIME Transducer 76.5 4-27, 4-58
Drive Signal DRIVE_SIGNAL Transducer 53 4-27, 4-50, 6-11
Effective Area EFFECTIVE_AREA Transducer 85.2 4-39, 4-62
Elect Active ELECT_ACTIVE Transducer 74.1 4-54
Elect Enable ELECT_ENABLE Transducer 75.1 4-57
Electronics Serial Number ELECTRONICS_SN Resource 49 4-6, 4-17, 6-5
Environment Active ENVIRO_ACTIVE Transducer 74.3 4-54
Environment Enable ENVIRO_ENABLE Transducer 75.3 4-57
Error ERROR PID 67 4-95
Factory Serial Number FACTORY_SN Resource 50 4-6, 4-17, 6-5
Failed Active FAILED_ACTIVE Transducer 59 4-40, 4-51
Failed Alarm FAILED_ALM Transducer 56 4-50
Failed Enable FAILED_ENABLE Transducer 62 4-35, 4-52
Failed Priority FAILED_PRI Transducer 68 4-53, C-3
−Continued−
