Table 4-85. Block Parameter Index (Continued)
Label Page Numbers
Index
Number
BlockParameter Name
Hystval HYSTVAL OS 22 4-124
IDeadBand IDEADBAND PID 74 4-96
Inlet Pressure INLET_PRESSURE Transducer 83.7 4-37, 4-61
Input IN PID 15 4-90
Input 1 IN_1 ISEL 11 4-107, 4-109
Input 2 IN_2 ISEL 12 4-107, 4-110
Input 3 IN_3 ISEL 13 4-107, 4-110
Input 4 IN_4 ISEL 14 4-107, 4-110
Input 5 IN_5 ISEL 25 4-107, 4-111
Input 6 IN_6 ISEL 26 4-107, 4-111
Input 7 IN_7 ISEL 27 4-107, 4-111
Input 8 IN_8 ISEL 28 4-107, 4-111
Input Array IN_ARRAY OS 16 4-124
Input Characterization INPUT_CHAR Transducer 50 4-26, 4-49, 6-11
I/O Options IO_OPTS
AI 13 4-135
AO 14 4-72, 4-74, 4-76
DI 13 4-163, 4-167
DO 14 4-152, 4-155
ITK Version ITK_VER Resource 41 4-7, 4-17, 6-6
Leak Class LEAK_CLASS Transducer 84.2 4-37, 4-61
Length Units LENGTH_UNITS Transducer 92 4-36, 4-63
Limit Notify LIM_NOTIFY Resource 32 4-6, 4-15
Linearization Type L_TYPE AI 16 4-130, 4-135
Lockval LOCKVAL OS 18 4-124
Low Alarm LO_ALM
AI 35 4-137
ISEL 47 4-113
PID 62 4-94
Low Cutoff LOW_CUT AI 17 4-131, 4-135
Lower Bench Set LOWER_BENCH_SET Transducer 85.4 4-39, 4-62
Low Limit LO_LIM
AI 30 4-129, 4-136
ISEL 42 4-108, 4-112
PID 53 4-87, 4-93
Low Low Alarm LO_LO_ALM
AI 36 4-137
ISEL 48 4-113
PID 63 4-94
Low Low Limit LO_LO_LIM
AI 32 4-129, 4-136
ISEL 44 4-108, 4-112
PID 55 4-87, 4-93
Low Low Priority LO_LO_PRI
AI 31 4-129, 4-136
ISEL 43 4-108, 4-112
PID 54 4-87, 4-93
Low Priority LO_PRI
AI 29 4-129, 4-136
ISEL 41 4-108, 4-112
PID 52 4-87, 4-93
MAI Channel 1 MAI_CHANNEL_1 Transducer 95.1 4-63
MAI Channel 2 MAI_CHANNEL_2 Transducer 95.2 4-63
MAI Channel 3 MAI_CHANNEL_3 Transducer 95.3 4-63
MAI Channel 4 MAI_CHANNEL_4 Transducer 95.4 4-63
MAI Channel 5 MAI_CHANNEL_5 Transducer 95.5 4-63
MAI Channel 6 MAI_CHANNEL_6 Transducer 95.6 4-63
MAI Channel 7 MAI_CHANNEL_7 Transducer 95.7 4-63
−Continued−
