FloBoss 107 Instruction Manual
1-4 General Information Revised June-2017
A
Slot 4 = I/O or MVS module
B
Slot 5 = I/O or MVS module
C
Connects to FloBoss 107 base unit
D
Slot 7 = I/O or MVS module
E
Slot 6 = I/O or MVS module
F
Wire Channel Cover
Figure 1-2. FloBoss 107 Expansion Rack
D
A
F
E
B
C
