S600+ Field Upgrade Guide
Overview
This guide describes the processes required to upgrade your FloBoss
S600 to a FloBoss S600+. Two general processes are involved:
replacing the CPU module and replacing the front panel faceplate. The
new CPU module provides increased processing speed, increased
memory, additional communication ports, and an enhanced operating
system, and represents a significant improvement from the current
CPU module. The new front panel faceplate provides the correct logos
and identifies the S600+.
Warning
This upgrade process is intended ONLY for systems which DO NOT
have MID approvals. To upgrade a system with MID approval, contact
your sales representative.
Security Plate
If you have a security plate currently installed on your S600, that plate
does not fit the new CPU module. A new security plate (part number
S600+EMCPLATE) is included in the upgrade kit.
Note: Refer to the S600+ technical specification (S600, available
from www.EmersonProcess.com/Remote) for further technical
details.
General Procedure
The procedure requires that you perform a number of steps in a
specific sequence:
1. Save the current configuration in the CPU module to your PC.
2. Power down the S600 and remove appropriate wiring.
3. Remove the front panel faceplate.
4. Install the printed circuit board (PCB) in the new faceplate.
5. Replace the front panel connector cable.
6. Reattach the front display panel to the S600 chassis.
7. Remove and safely store the old CPU module.
8. Unpack the new S600+ CPU module from its shipping container
and anti-static bag.
9. Set communication jumpers.
10. Set security jumper.
11. Set cold start jumper.
12. Install the new CPU module in the chassis.
13. Wire the new CPU module.
14. Apply power.
15. Set TCP/IP communications parameters.
16. Download configuration.
17. Perform a cold start.
The following pages discuss each of these steps in detail.
