Emerson Micro Motion ELITE - Installation Process Overview; Step 1. Location; Step 2. Orientation; Step 3. Mounting

Figure 2-1: Installation for self-draining applications
A
B
C
A. Process pipeline
B. Direction of normal process flow
C. Direction of drainage
Installation Manual Planning
20002158 October 2021
Installation Manual 13
