# Access Name Type Value Comments
8 Get Node Address Padded EPATH - -
B.2.5 TCP/IP Interface Object, Class F5h
This object groups TCP/IP-related settings.
Supported services
Class services:
• Get Attribute All
• Get Attribute Single
Instance services:
• Get Attribute All
• Get Attribute Single
• Set Attribute Single
Class attributes
# Access Name Type Value Comments
1 Get Revision UINT 0001h Revision 1
2 Get Max Instance UINT 0001h 1 is the highest instance number
3 Get No. of instances UINT 0001h 1 instance is implemented
Instance attributes
#
Access Name Type Value Comments
1 Get Status DWORD 00000001h Attribute #5 contains valid
information.
2 Get Configuration
Capability
DWORD 00000016h Attribute #5 is settable. Capable of
obtaining network configuration
via DHCP.
3 Get/Set Configuration Control DWORD - 0: Configuration from non-volatile
memory
2: Configuration from DHCP
4 Get Port Object Struct of:
Path Size UINT 0002h 2 words
Path Padded EPATH 20 F6 24 01h Path to Ethernet Class, Instance 1
5 Get/Set Interface
Configuration
Struct of:
IP Address UDINT - IP address
Device profile User Guide
January 2019 MMI-20019808
40 Micro Motion EtherNet/IP Module
