Byte Access Name Type Notes
80–81 Get Status word U16 or Word • For Model 1700 Analog, Model 2700 Analog,
Model 1500 Analog, Model 2500, and all Series
3000 transmitters: SNS Status Word 1 (see
Status Word 1)
• For MVD Direct Connect and 9739 MVD
transmitters: SNS Status Word 2 (see Status
Word 2)
82–83 Get Status word U16 or Word • For Model 1700 Analog, Model 2700 Analog,
Model 1500 Analog, Model 2500, and all Series
3000 transmitters: SNS Status Word 2 (see
Status Word 2)
• For MVD Direct Connect and 9739 MVD
transmitters: SNS Status Word 1 (Status Word
1)
B.3.6 Output assembly for concentration measurement
configuration
Byte Access Name Type Notes
0–3 Get/Set External Temperature Float
4–7 Get/Set External Pressure Float
8 Get/Set Start/Stop Totals Byte 0: Stop
1: Start
9 Get/Set Reset All Process Totals Byte 0: No action
1: Reset
10 Get/Set Reset All Inventory Totals Byte 0: No action
1: Reset
11 Get/Set Start Zero Byte 0: Abort or no action
1: Start
12–13 Get/Set Start Smart Meter
Verification
Word See Table B-20
B.3.7 Input parameters (explicit data) for concentration
measurement configuration
To update any of these attribute values, the associated trigger byte must be toggled
before reading the attribute value (executing the Get service). See Output parameters
(explicit data) for standard configuration for more information on trigger bytes.
User Guide
Device profile
MMI-20019808 January 2019
User Guide 49
