Attribute Access Name Type Trigger Byte
WriteAttribute
Description
19h Get Smart Meter Verification
Progress
U16 10h % complete
1Ah Get Concentration units code U8 13h
1Bh Get Derived variable U16 12h See Table B-17
1Ch Get Active matrix U16 12h
1Dh Get Subnet communication status
(RS-485 connection to
transmitter)
U16 No trigger byte 0: Communications failure
Any other value:
Communications good
B.3.8 Output parameters (explicit data) for concentration
measurement configuration
Class B1h, Instance 01h
Attribute Access Name Type Trigger byte
write attribute
Description
01h Get/Set Standard or special mass flow
rate unit
U16 See Table B-7
02h Get/Set Density unit U16 See Table B-13
03h Get/Set Temperature unit U16 See Table B-14
04h Get/Set Standard or special volume
flow rate unit
U16 See Table B-10
05h Get/Set Pressure unit U16 See Table B-15
06h Get/Set Zero time U16 Seconds
07h Get/Set Zero value Float
08h Get/Set Output state during Smart
Meter Verification
U16 0 = Last measured value
1 = Fault
09h Get/Set Smart Meter Verification Index U16 11h Smart Meter Verification test
record.
0 = most recent
...
19 = oldest
0Ah Get/Set Trigger Byte-2 U8
0Bh Get/Set Trigger Byte-3 U8
0Ch Get/Set Trigger Byte-6 U8
User Guide Device profile
MMI-20019808 January 2019
User Guide 51
