Instruction Manual Section 5: Programming Basics
LIQ-MAN-56 April 2017
Programming Basics 37
Section 5.0. Programming the Analyzer - Basics
5.1 General
Typical programming steps include the following listed procedures. Each of these programming
functions are easily and quickly accomplished using the intuitive menu systems.
• Changing the measurement type, measurement units and temperature units.
• Choose temperature units and manual or automatic temperature compensation mode
• Configure and assign values to the current outputs
• Set a security code for two levels of security access
• Accessing menu functions using a security code
• Enabling and disabling Hold mode for current outputs
• Choosing the frequency of the AC power (needed for optimum noise rejection)
• Resetting all factory defaults, calibration data only, or current output settings only
5.2 Changing Startup Settings
To change the measurement type, measurement units, or temperature units that were initially
entered in Quick Start, choose the Reset function or access the Program menus for sensor 1 or
sensor 2. The following choices for specific measurement type, measurement units are
available for each sensor measurement board.
Signal board Available measurements
Measurements units:
pH/ORP (-22, -32)
pH, ORP, Redox, Ammonia, Fluoride,
Custom ISE
pH, mV (ORP)
%, ppm, mg/L, ppb,
µ
g/L, (ISE)
Contacting conductivity
(-20, -30)
Conductivity, Resistivity, TDS, Salinity,
NaOH (0-12%), HCl (0-15%), Low H2SO4,
High H2SO4, NaCl (0-20%),
Custom Curve
µ
S/cm, mS/cm, S/cm
% (concentration)
Toroidal conductivity
(-21, -31)
Conductivity, Resistivity, TDS, Salinity,
NaOH (0-12%), HCl (0-15%), Low H2SO4,
High H2SO4, NaCl (0-20%),
Custom Curve
µ
S/cm, mS/cm, S/cm
% (concentration)
Chlorine
(-24, -34)
Free Chlorine, pH Independ. Free Cl, Total
Chlorine, Monochloramine
ppm, mg/L
Oxygen
(-25, -35)
Oxygen (ppm), Trace Oxygen (ppb),
Percent Oxygen in gas, Salinity
ppm, mg/L, ppb, µg/L % Sat, Partial
Pressure, % Oxygen In Gas, ppm
Oxygen In Gas
Ozone (-26, -36) Ozone
ppm, mg/L, ppb,
µ
g/L
Temperature (all)
Temperature °C / °F
TABLE 5-1. Measurements and Measurement Units
