1. Refer to Section 2.0 for mechanical installation instructions.
2
. Wire sensor(s) to the signal boards. See Section 3.0 for wiring instructions. Refer to the
sensor instruction sheet for additional details. Make current output, alarm relay and
power connections
3. Once connections are secured and verified, apply power to the analyzer.
4. When the analyzer is powered up for the first time, Time/Date and Quick Start screens
appear. Quick Start operating tips are as follows:
a. Window screens will appear. The field with the focus will appear with dark blue back-
lighting. The field with focus can be edited by press ENTER/MENU.
b. The Time and Date screen to set the real-time clock will appear. Accept the displayed
time by pressing ENTER on Time and date OK or press the down key to Change the
time and date.
c. The first Quick Start screen appears. Choose the desired language by pressing
ENTER/MENU to edit the active field and scrolling to the language of choice. Press
ENTER/MENU and press the down arrow to highlight NEXT.
d. The Navigation Rules for operating the keypad will be displayed.
e. Choose the measurement for Sensor 1 (and Sensor 2) and proceed to the remaining
Quick Start steps.
f. Keypad operation guidelines will appear to guide the user how operate the user inter-
face.
g. NOTE: To edit a field with backlit focus, press ENTER/MENU. To scroll up or down, use
the keys to above or below the ENTER key. To move the cursor left or right, use the
keys to the left or right of the ENTER key. To edit a numeric value including decimal
points, use the alphanumeric keypad then press ENTER.
h. NOTE: Press ENTER to store a setting or value. Press EXIT to leave without storing
changes. Pressing EXIT during Quick Start returns the display to the initial start-up
screen (select language). To proceed to the next Quick Start step, use the right key or
the down key to highlight NEXT. Press ENTER.
5. After the last step, the main display appears. The current outputs are assigned to default
values before probes are wired to the analyzer. After the last step, the main display ap-
pears. The outputs are assigned to
default values.
6. To change output, and all settings, press ENTER/MENU from the live screen. Using the
down and right arrow keys, select one of the following menus and navigate the screen of
choice.
7. To return the analyzer to the default settings, choose Reset under the Menu selection
screen.
WARNING
RISK OF ELECTRICAL SHOCK
Electrical installation must be in accordance with the National Electrical Code
(ANSI/NFPA-70) and/or any other applicable national or local codes.
CAUTION: This symbol identifies a risk of electrical shock.
CAUTION: This symbol identifies a potential hazard. When this symbol
appears, consult the manual for appropriate action.
