The rst line gives you the choice to cancel
the procedure now.
Select the second line to start the calibra-
tion.
The next lines show
• the calibration gas setup (here: required
zero gas concentration is 0.000 ppm),
• the currently measured gas concentration
• and the current gas ow, if a ow sensor
is installed.
Ch1
Zero calibration
Cancel!
Start!
Zero gas 0.000 ppm
Concentration 0.000 ppm
Flow 0.00 l/min
Status..
Results..
Restore!
4.1 Perform a calibration
When nished press left several times to
return to either
SELECT COMPONENT (multi channel ana-
lyzer only), to perform a zero calibration for
another channel,
or
to CONTROL, where you may start a span
calibration. The procedure and screens look
similiar to those of a zero calibration:
