Emerson Process Management GmbH & Co. OHG1-6
X-STREAM XE
Short Form Manual
HASXEE-SFM-HS
05/2017
1.3 X-STREAM XEGK: ½ 19 Inch Table-Top Unit
1.3 X-STREAM XEGK
This compact model for general purposes
can be tted with up to three measurement
channels in various combinations. Power is
supplied by an internal wide range power sup-
ply or a separate external power supply unit.
By default the units are congured for tabletop
use. A carrying handle is optional available
which makes it easy to take the instrument
to varying sampling points. For rack mount-
ing a XEGK is xed by screws located at the
front panel.
Connection to power supply
AC is supplied by an IEC chassis plug with
power switch and fuse holders. The internal
wide range power supply unit enables the
analyzers to be used worldwide. Optionally
DC 24 V power is supplied via a 3-pin socket
at the rear of the unit.
Interfaces
Electrical connections for interface signals are
provided via submin-D connectors, Ethernet
and USB connectors mounted on the rear
panel of the device
(
Fig. 1-2
).
Gas connections
Depending on the conguration of the unit
(number of measurement channels and serial
or parallel connection), sample and calibra-
tion gases are fed into the unit via up to 8
tube ttings mounted on the rear panel. Any
free tube ttings can be used for purging the
device
to minimize interference from the ambi-
ent atmosphere,
or
when measuring corrosive
and/or ammable gases.
