When done, press left several times to return
to SETUP, and then enter MEASUREMENT.
Setup..
Measurement..
Ch1
Measurement 1of2
Ranges..
Damping..
Linearization..
Cross Interference..
Average..
Delay..
Ch1
Measurement 2of2
Cut-off: None
Pressure Compensation ..
Ch1
Pressure compensation
Manual Pressure: 1013 hPa
Pressure 1013 hPa
Pressure Status Good
Damping enables to smooth the analog out-
puts signals, but also increases the reaction
times of outputs and display:
• By default, damping is set to 0 seconds.
• The maximum t
90
time is limited by the
available internal data buffer and by the
sampling rates of the analyzer‘s measuring
systems.
• Multi-channel instruments: Setup damping
separately for each channel.
The last line on menu page 2of2 opens a
new menu
• to manually enter the current atmospheric
pressure (if no pressure sensor is installed),
or
• to show the current atmospheric pressure,
if a pressure sensor is installed.
Proper values for atmospheric pressure are
required for pressure compensation of mea-
surement values!
With manual entry, update this value regularly
to achieve proper measurements.
4.1 Perform a Calibration
