Unidrive M100 / M101 Control User Guide 43
Issue Number: 1
Displays the type/mode of the data block selected with Pr 11.037.
Displays the version number of the file selected in Pr 11.037.
9.4 NV Media Card trips
After an attempt to read, write or erase data from a NV Media Card a trip
is initiated if there has been a problem with the command.
See Chapter 11 Diagnostics on page 80 for more information on NV
Media Card trips.
9.5 Data block header information
Each data block stored on a NV Media Card has header information
detailing the following:
• NV Media Card File Number (11.037)
• NV Media Card File Type (11.038)
• NV Media Card File Version (11.039)
The header information for each data block which has been used can be
viewed in Pr 11.038 to Pr 11.039 by increasing or decreasing the data
block number set in Pr 11.037. If there is no data on the card Pr 11.037
can only have a value of 0.
11.038 NV Media Card File Type
RO Txt ND NC PT
Ú
0 to 1
Ö
0
Pr 11.038 String Type / mode
0 None No file selected
1 Open-loop Open-Loop mode parameter file
11.039 NV Media Card File Version
RO Num ND NC PT
Ú
0 to 9999
Ö
0
11.042 {00.030} Parameter Cloning
RW Txt NC US
Ú
NonE (0), rEAd (1), Prog
(2), Auto (3),
boot (4)
Ö
0
