Unidrive M100 / M101 Control User Guide 75
Issue Number: 1
10.052 Trip 5 Time 00:00:00 to 23:59:59 RO Time ND NC PT PS
10.053 Trip 6 Date 00-00-00 to 31-12-99
RO Date ND NC PT PS
10.054 Trip 6 Time 00:00:00 to 23:59:59
RO Time ND NC PT PS
10.055 Trip 7 Date 00-00-00 to 31-12-99
RO Date ND NC PT PS
10.056 Trip 7 Time 00:00:00 to 23:59:59
RO Time ND NC PT PS
10.057 Trip 8 Date 00-00-00 to 31-12-99
RO Date ND NC PT PS
10.058 Trip 8 Time 00:00:00 to 23:59:59
RO Time ND NC PT PS
10.059 Trip 9 Date 00-00-00 to 31-12-99
RO Date ND NC PT PS
10.060 Trip 9 Time 00:00:00 to 23:59:59
RO Time ND NC PT PS
10.061 Braking Resistor Resistance 0.00 to 10000.00  0.00  RW Num US
10.065 Autotune Active Off (0) or On (1)
RO Bit ND NC PT
10.066 LimitSwitchActive Off(0)orOn(1)
RO Bit ND NC PT
10.068
Hold Drive Healthy On Under
Voltage
Off (0) or On (1) Off (0) RW Bit US
10.069 Additional Status Bits 0 to 2047
RO Num ND NC PT
10.070 Trip 0 Sub-trip Number 0 to 65535
RO Num ND NC PT PS
10.071 Trip 1 Sub-trip Number 0 to 65535
RO Num ND NC PT PS
10.072 Trip 2 Sub-trip Number 0 to 65535
RO Num ND NC PT PS
10.073 Trip 3 Sub-trip Number 0 to 65535
RO Num ND NC PT PS
10.074 Trip 4 Sub-trip Number 0 to 65535
RO Num ND NC PT PS
10.075 Trip 5 Sub-trip Number 0 to 65535
RO Num ND NC PT PS
10.076 Trip 6 Sub-trip Number 0 to 65535
RO Num ND NC PT PS
10.077 Trip 7 Sub-trip Number 0 to 65535
RO Num ND NC PT PS
10.078 Trip 8 Sub-trip Number 0 to 65535
RO Num ND NC PT PS
10.079 Trip 9 Sub-trip Number 0 to 65535
RO Num ND NC PT PS
10.080 Stop Motor Off (0) or On (1)
RO Bit ND NC PT
10.081 Phase Loss Off (0) or On (1)
RO Bit ND NC PT
10.090 Drive Ready Off (0) or On (1)
RO Bit ND NC PT
10.101 Drive Status
Inh (0), rdy (1), StoP (2), ScAn (3), rES (4),
S.LoSS (5), rES (6), dc.inJ (7), rES (8),
Error (9), ActivE (10), rES (11), rES (12),
rES (13), HEAt (14), UU (15)
RO Txt ND NC PT
10.102 Trip Reset Source 0 to 1023
RO Num ND NC PT PS
10.103 Trip Time Identifier -2147483648 to 2147483647 ms
RO Num ND NC PT
10.104 Active Alarm
NonE (0), br.rES (1), OV.Ld (2), rES (3),
d.OV.Ld (4), tuning (5), LS (6), rES (7),
rES (8), rES (9), rES (10), rES (11),
rES(12), Lo.AC (13), I.AC.Lt (14),
24.LoSt (15)
RO Txt ND NC PT
10.106
Potential Drive Damage
Conditions
0to 3
RO Bin ND NC PT PS
10.107 Low AC Alarm Off (0) or On (1)
RO Bit ND NC PT
10.108 Reversed cooling fan detected Off (0) or On (1)
RO Bit ND PT
RW Read / Write RO Read only Num Number parameter Bit Bit parameter Txt Text string Bin Binary parameter FI Filtered
ND No default value NC Not copied PT Protected parameter RA Rating dependent US User save PS Power-down save DE Destination
Date Date parameter Time Time parameter
Parameter
Range
(Ú) Default (Ö)
Type
OL OL
