Operating Temperature : -25°C to 70°C
Max. Operating Humidity : 90% Rh (non-condensing)
Altitude : Up to 2000m.
Operating Conditions
Forbidden Conditions:
Corrosive atmosphere
Explosive atmosphere
Home applications (The unit is only for industrial applications)
2.4 Environmental Ratings
c
10
During installation into a metal
panel, care should be taken to
avoid injury from metal burrs
which might be present. The
equipment can loosen from
vibration and become dislodged if
installation parts are not properly
tightened. These precautions for
the safety of the person who does
the panel mounting.
1. Prepare the panel cut-out in the
correct dimensions.
f fixing parts are on the
unit unscrew the fixing screws in the
fixings parts to remove the fixings
parts.
Maximum panel
thickness is 7mm (0.28 inch)
2. Insert the unit in the panel cut-out
from the front. I
2.5 Panel Mounting
c
Fixing part Fixing screw
1
22
To Next Page
