EMKO esm-4450 - Current Transformer Connection to Emi-420 0; Vct Input; Connection of Emi-430 Tc or 0

0...5AV
0...5AV
5.1.5ConnectionofEMI-430TC(Thermocouple)or0...50mV InputModuleZ
Two EMI-420 CT input modules can not be plugged in Module-1 and Module-2
socket at the same time.
V
Current
Transformer
(CT)
Load
5.1.4CurrentTransformerConnectiontoEMI-4200...5 A CTInputModuleV
33
8
Module-1
7
0.1 W
Current
Transformer
(CT)
Load
10
Module-2
9
Connect the wires with the polarity as shown above. Always use compensation wire
corresponding to the thermocouple used. If present, the shield must be connected to a proper
ground.
10
Module-2
9
8
Module-1
7
TC TC
0.1 W
EMI-410, EMI-430, EMI-440 or EMI-450 analogue input modules can not be
plugged-in Module-1 and Module-2 socket at the same time.
