EMS 5000 FIREPOINT
©2015 EMS Security Group Ltd. All rights reserved. TSD258 Iss 3 25/06/15 AJM
29
f) ALL OFF : The selected sounder will stop sounding. (i.e. Silence)
g) RX TEST : The receiver in the selected sounder will be sent a test
message, the sounder will receive the message and send an
acknowledgement message back to the 5000 FirePoint panel.
h) TEST: The selected sounder will sound for four seconds and then
turn off. The sounder will listen to it self and send an
acknowledgement message back to the 5000 FirePoint panel.
i) SET SYS: The 5000 FirePoint panel will send a message to the select
sounder, which sets the system code in the selected sounder. The
sounder then sends an acknowledgement message back to the 5000
FirePoint panel.
j) JOIN GRP: The 5000 FirePoint panel will send the zone information
to the selected sounder, the selected sounder sends an
acknowledgement back to the 5000 FirePoint panel.
k) SET LS CH: The 5000 FirePoint panel will send a message to the
selected sounder which enables the lesson change, feature for the
device.
15 Press key once and the screen will display:
16 Press Yes key and the screen will now display:
This timer will count down to 0, when the timer reaches 0 the retry
should change to 6 and a message is sent to the sounder. If not, that
means the panel is still busy and the timer will start again, when the
retry number decreases listen for the selected sounder to activate.
When the selected sounder has activated it sounds for four seconds
and resets itself, watch the display for the acknowledgement
message. (ACK)
If the acknowledgement message has been received and a fault has
not been reported the test is now complete.
|Action : TEST |
>Do Action <
|^^^^^^^^^^^^^^^^^|
Yes= Select Time
Device 025 Timer 9
Retry 07 REPLY NONE
Push Any Key Time
Device 025 Timer 5
Retry 04 REPLY ACK
Push Any Key Time
