16.3 Display Board Adjustment Points
The drawing below shows the adjustment points on the display board. The display glass has to be removed in order to access these
adjustments, on the front panel of the DX-2.
Unless you know very well what you are doing and you have a reason to do it, do not modify any adjustment!
ALL POTENTIOMETERS: Rotating counter-clockwise will increase the sensitivity and increase the indication.
RF OUTPUT POWER
(
kW
)
REFLECTED POWER
(
W
)
PLATE VOLTAGE
(
kV
)
PLATE CURRENT
(
A
)
I
g
2
OVER
DRIVE
ON AIR
READY
SWR
FAULT
Po F
Po R
+Ig2
-Ig2
VOLT
AMP
