Endress+Hauser CM442R - Protocol-Specific Data; Profibus Dp

Liquiline CM442R/CM444R/CM448R
Endress+Hauser 23
PROFIBUS DP
Manufacturer ID 11
h
Device type 155D
h
Profile version 3.02
GSD files www.endress.com/profibus
Device Integration Manager DIM
Output values 16 AI blocks, 8 DI blocks
Input variables 4 AO blocks, 8 DO blocks
Supported features • 1 MSCY0 connection (cyclical communication, master class 1
to slave)
• 1 MSAC1 connection (acyclical communication, master class 1
to slave)
• 2 MSAC2 connections (acyclical communication, master class
2 to slave)
• Device lock: The device can be locked using the hardware or
software.
• Addressing using DIL switches or software
• GSD, PDM DD, DTM
Modbus RS485
Protocol RTU/ASCII
Function codes 03, 04, 06, 08, 16, 23
Broadcast support for function codes 06, 16, 23
Output data 16 measured values (value, unit, status), 8 digital values (value,
status)
Input data 4 setpoints (value, unit, status), 8 digital values (value, status),
diagnostic information
Supported features Address can be configured using switch or software
Modbus TCP
TCP port 502
TCP connections 3
Protocol TCP
Function codes 03, 04, 06, 08, 16, 23
Broadcast support for function codes 06, 16, 23
Output data 16 measured values (value, unit, status), 8 digital values (value,
status)
Input data 4 setpoints (value, unit, status), 8 digital values (value, status),
diagnostic information
Supported features Address can be configured using DHCP or software
EtherNet/IP
Protocol EtherNet/IP
ODVA certification Yes
Device profile Generic device (product type: 0x2B)
Manufacturer ID 0x049E
h
Device type ID 0x109C
h
Polarity Auto-MIDI-X
Connections CIP 12
I/O 6
Explicit message 6
Multicast 3 consumers
Minimum RPI 100 ms (default)
