Liquiline CM442R/CM444R/CM448R
Endress+Hauser 39
Service display (accessories)
The service display comprises:
• Portable display (same dimensions as under "Optional display")
• Cover to protect the display and to hook it onto the (open) cabinet door
A A
B
B
B-B
A-A
193 (7.60)
123 (4.84)
157 (6.18)
119 (4.69)
R16
13.5 (0.53)
36 (1.42)
143 (5.63)
40 (1.57)
47 (1.85)
144.5 (5.69)
A0025343
 33 Dimensions of the service display cover in mm (inch)
Weight
Depending on version:
CM442R (fully configured)
Approx. 0.45 kg (1 lbs)
CM444R and CM448R (fully configured) Approx. 0.95 kg (2.1 lbs)
Individual module Approx. 0.06 kg (0.13 lbs)
External display (excluding cables) Approx. 0.56 kg (1.2 lbs)
Service display cover 0.46 kg (1 lbs)
External power unit (CM444R, CM448R) 0.27 to 0.42 kg (0.60 to 0.92 lbs), depending on the power
unit variant
Materials
DIN rail housing PC-FR
Display cover PC-FR
Display seal EPDM
Soft keys EPDM
Module covers PBT GF30 FR
Terminal strip Nickel-plated brass
Ground terminals Stainless steel 1.4301 (AISI304)
Threaded fasteners Stainless steel 1.4301 (AISI304)
Mounting plate (display) Stainless steel 1.4301 (AISI304)
Securing screws (display) Steel, galvanized
Cover for service display (accessories) EPDM
