Liquiline CM442R/CM444R/CM448R
24 Endress+Hauser
Maximum RPI 10000 ms
System integration EtherNet/IP EDS
Rockwell Add-on-Profile Level 3, Faceplate for Factory
Talk SE
IO data Input (T → O) Device status and diagnostic message with
highest priority
Measured values:
• 16 AI (analog input) + Status + Unit
• 8 DI (discrete input) + Status
Output (O → T) Actuating values:
• 4 A0 (analog output) + status + unit
• 8 DO (discrete output) + Status
Web server
The web server enables full access to the device configuration, measured values, diagnostic
messages, logbooks and service data via standard WiFi/WLAN/LAN/GSM or 3G routers with a user-
defined IP address.
TCP port 80
Supported features • Remote-controlled device configuration(1 session)
• Save/restore device configuration (via SD card)
• Logbook export (file formats: CSV, FDM)
• Access to web server via DTM or Internet Explorer
• Login
• Web server can be switched off
Power supply
Supply voltage
CM442R
Depending on version:
• 100 to 230 V AC ± 15 %, 50/60 Hz
• 24 V AC/DC +20/-15 %, 50/60 Hz
CM444R and CM448R
Depending on version via external DIN rail power unit:
• 100 to 230 V AC ± 15 %, 50/60 Hz
• 24 V DC +20 / -15 %
NOTICE
The device does not have a power switch
‣
The customer must provide a protected circuit breaker in the vicinity of the device.
‣
The circuit breaker must be a switch or power switch, and you must label it as the circuit breaker
for the device.
‣
At the supply point, the power supply for the 24 V versions must be isolated from dangerous live
cables by double or reinforced insulation.
Fieldbus connection
Supply voltage: not applicable
Power consumption
CM442R
Depending on supply voltage
• 100 to 230 V AC and 24 V AC:
Max. 55 VA
• 24 V DC:
Max. 22 W
CM444R and CM448R
Depending on supply voltage
• 100 to 230 V AC:
Max. 150 VA
• 24 V DC:
Max. 59 W
