3. Installation
3.1 Unit dimensions
Fig. 3.2: Dimensions of
(left) Mycom CLM 151
➀
Mounting brackets for wall
mounting
Fig. 3.3: Rear of field housing
(right) with installed mounting
brackets
Note:
Mounting brackets and screws are
included in the scope of supply as
housing mounting kit.
167
247
LM151A02.EPS
188
153
95
PM151A09.EPS
80
80
➀
96
96
LM121MAS.EPS
Fig. 3.1: Dimensions of
Mycom CLM 121
BE1LM151.CHP
