8. Technical data
8.1 Electrical data
Conductivity measurement
Conductivity meas. ranges of version CD . . . . . . . . . . . . . 0 … 2.0 µS / cm ; 0 …1000 mS / cm
Concentration ranges (fixed). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 … max. 15 % NaOH
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 … max. 20 % HNO
3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 … max. 20 % H
2
SO
4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 ... max. 12 % H
3
PO
4
Concentration ranges (user-defined) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 … 99.99 %
Conductivity meas. ranges of version MM. . . . . . . . . . . . . . . . 0 ... 1 µS / cm , 0 ... 20 MΩ x cm
Measured value display . . . . . . . . . . . . . . . . LC display, 4 digits, 7 segments, height = 10 mm
Status indication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . LEDs red or red / green
Indication errors of measurement / display / current output (DIN IEC 746) . . . . . 0.2 % / 0.5 %
Cell constants. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.01 … 50
Measuring frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . CD = 300 Hz … 5 kHz, MM = 30 Hz
Alternating measuring voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ≤ 625 mV
Remote switching of measuring range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . factor 10
Current range of conductivity signal output. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 / 4 … 20 mA
Load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . max. 600 Ω
Signal output range
– linear . . . . . . . . . . . . . . . . . . . 20 … 100 % of meas. range (adjustable in absolute values)
– bilinear. . . . . . . 0 … 10 % of meas. range
^
0 …50 % current range (0 / 4 … 10 / 12 mA)
. . . . . . . . . . . . . . 10 … 110 % of meas. range
^
0 …50 % current range (10 / 12 … 20 mA)
Temperature measurement
Temperature measuring range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . –15 … +200 °C
Temperature signal output (option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 / 4 … 20 mA
Load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . max. 400 Ω
Temperature output range . . . . . . . . . . . . . . . . . . . . . . . . . . . adjustable from ∆ 50 … ∆ 215 °C
Temperature sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pt 100 with 3-wire switching
Indication error of measurement (to DIN IEC 746) . . max. 0.5 % of meas. range up to 150 °C
max. 1.0 % of meas. range up to 200 °C
Limit value, controller and alarm functions
Limit contacterr / 2-point controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . max. 2 limit contacts
Controller function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . limit value
Type of function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . MIN or MAX (direct or inverted)
Setpoint adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . 2 x 0 … 100 % of FS (in absolute values)
Setpoint hysteresis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 … 10 % of FS (in absolute values)
Contact delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pickup / dropout
– Delay period. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 … 6000 s
Alarm threshold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.5 … 30 % of FS (in absolute values)
– Alarm delay period . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 … 6000 s
