Proline Prosonic Flow 93 Scope of the Brief Operating Instructions
Endress+Hauser
3
1 Scope of the Brief Operating Instructions
Many versions of the Prosonic Flow 93 measuring system are available to suit different
applications. These Brief Operating Instructions describe how to use the Prosonic Flow P and W
versions (Clamp-on with strapping bands) and determine the installation distances via the
transmitter.
The procedure to be followed for all other versions is described in the Operating Instructions on
the CD-ROM.
1.1 Overview of information sources
Transmitter Sensor Type of mounting Traverses Description
Prosonic Flow 93 P (DN 15 to 65 /
½ to 2½")
Clamp-on 2 In these Brief Operating
Instructions and in the Operating
Instructions on the CD
Prosonic Flow 93 P (DN 50 to 4000 /
2 to 160")
Clamp-on
(Strapping band)
1 In these Brief Operating
Instructions and in the Operating
Instructions on the CD
2
Clamp-on
(welded bolts)
1 In the Operating Instructions on
the CD
2
Prosonic Flow 93 W (DN 15 to 65 /
½ to 2½")
Clamp-on 2 In these Brief Operating
Instructions and in the Operating
Instructions on the CD
Prosonic Flow 93 W Clamp-on 1 In these Brief Operating
Instructions and in the Operating
Instructions on the CD
2
Clamp-on
(welded bolts)
1 In the Operating Instructions on
the CD
2
Insertion version 1
2
Accessories for sound
velocity measurement
DDU18 Clamp-on 1 In the Operating Instructions on
the CD
Accessories for wall
thickness
measurement
DDU19 Clamp-on – in the Operating Instructions on
the CD
Determining installation distances via: Description
Transmitter (run a Quick Setup) In these Brief Operating
Instructions and in the Operating
Instructions on the CD
FieldCare (operating software) in conjunction with the transmitter In the Operating Instructions on
the CD
Applicator (online via the Endress+Hauser Internet site) In the Operating Instructions on
the CD
