Endress+Hauser Prosonic S Series - Blocking Distance; Transmitter

Prosonic S FDU90/91/91F/92/93/95/96
4 Endress + Hauser
Blocking distance The level L may not extend into the blocking distance BD. Level echoes within the blocking distance can not
be evaluated due to the transient characteristics of the sensor and thus a reliable measurement is not possible.
The blocking distance BD is dependent on the type of sensor:
L00-FDU9xxxx-05-00-00-xx-002
A: without flooding protection tube; B: with flooding protection tube
Transmitter The sensors can be connected to the transmitter FMU90. The transmitter recognizes the type of sensor
automatically.
FDU91
FDU92
FDU90
0.07 m
(0.23 ft)
0.3 m (1 ft)
0.4 m (1.3 ft)
FDU93
0.6 m (2 ft)
AB
FDU96
FDU95
1.6 m (5.25 ft)
FDU95-#2###: 0.9 m (3 ft)
FDU95-#1###: 0.7 m (2.3 ft)
