Endress+Hauser Soliphant M FTM51 Technical Information

Soliphant M FTM50, FTM51, FTM52
Endress+Hauser 19
Process connections
*
1
overall length standard fork
*
2
overall length short fork
*
3
fork length standard fork
*
4
fork length short fork
Process
connection
Code Dimensions (FTM50) Accessories Pressure
Temperature
(for FTM50/51)
NPT 1½
ANSI B 1.20.1
Sensor
ø1.67"
ø43 mm
R 1½
ANSI B 1.20.1
GJ
GG
L00-FTM5xxxx-06-05-xx-en-004
max. 25 bar
max. 150 °C
NPT 1½
ANSI B 1.20.1
Sensor
ø1.38"
ø36 mm
GX
L00-FTM5xxxx-06-05-xx-en-006
max. 25 bar
max. 150 °C
NPT 1¼
ANSI B 1.20.1
Sensor
ø1.38"
ø36 mm
GK
L00-FTM5xxxx-06-05-xx-en-005
max. 25 bar
max. 150 °C
Flange
ANSI B 16.5
EN 1092-1
(DIN 2527 B)
JIS B 2238
A#
B#
K#
L00-FTM5xxxx-06-05-xx-xx-007
Seal according to
design
Installed on site
In conformity with
FDA*
See nominal
pressure of flange,
however
max. 25 bar
max. 150 °C
Tri-Clamp
2" = ø64.0 mm
ISO 2852
TD
L00-FTM5xxxx-06-05-xx-xx-008
Clamping ring and
front seal
Installed on site
In conformity with
FDA*
max. 16 bar
max. 120 °C
max. 2 bar
max. 150 °C
* Material in conformity with FDA as per 21 CFR Part 177.1550/2600
*1 = 200; *2 = 145
ø 43
*3 = 155; *4 = 10020.5
50/2"AF
*2 = 145
ø 36
*4 = 100
20.5
50/2"AF
*2 = 145
ø 36
*4 = 10020.5
45 / 1¾"AF
*1 = 215; *2 = 160
ø 43
*3 = 155; *4 = 100
*1 = 215; *2 = 160
ø 43
*3 = 155; *4 = 100
