5 Operation
4. Hold down + to open the quick hitch.
Hold them down until the quick hitch is fully open.
5.2.2.2. Disconnecting the tool, hydraulic lock
REMARKS
Follow the manufacturer's instructions for connecting and
disconnecting tools if you do not use a Q-Safe quick hitch.
1. The locking cylinders are activated.
In the case of Q-Safe , the closed position is
achieved when the orange indicator rod no longer
protrudes from the quick hitch. The sound and light
signals are activated.
CAUTION
Use hearing protection when close to or handling
the Q-Safe quick hitch when it is connected. Risk of
hearing damage.
In the case of ECPUP, open position is achieved when the red hook is in the open
position.
33
