5 Operation
In the case of engcon's other quick hitch locks, the open position is achieved when the
blue indicator rod is visible. Indicator rod location may vary depending on the tiltrotator
model.
If you have a different quick hitch, check that the lock function has engaged as specified
for the quick hitch concerned.
In this position the tool is free !
2. The locking bolts are now in the open position and
the tool is free. Carefully raise the tiltrotator from the
tool.
IMPORTANT
The machine may only be operated with the quick hitch
lock switch in the activated position when connecting and
disconnecting tools.
5.2.2.3. Close the tiltrotator quick hitch (QH)
?
1.
1.
2.
2.
3.
3.
